product
Ultrasonic Gas Meter
Ultrasonic gas meter is a new type of gas metering terminal, which uses the time difference of ultrasonic transmission in the medium to measure the gas flow. It is mainly used to measure the gas flow in the pipeline. It uses the wireless communication technology such as GFSK, LoRa, GPRS, NB-ioT to realize the functions of step gas price, wireless remote transmission, remote valve control, abnormal flow monitoring, etc.The cost of human resources and network deployment for gas companies has been greatly reduced.
Technical parameters
Basic technical parameters
Parameter nameunitModel and specification
 RU06-WL-G6
 RU06-WL-G10
RU06-WL-G16
Maximum flowm3/h
10
16
25
Maximum working pressurekPa50
Maximum allowable errormmqmin  ≤ q < qtwhen，±3%
qt  ≤ q ≤ qmaxwhen，±1.5%
Operating temperature℃-10~+40
airtightness/Input 1.5 times the maximum working pressure of air, for three minutes without leakage
Valve life次≥10000
Precision class/Level 1.5
Static current

μA

≤50
Operating frequency band

MHz

NB-IoT 800MHz / 900MHz/1800MHz

無線發(fā)射功率

dBm

≤23


尺寸圖：

Model/sizeMSLBHDquality（kg）

RU06-WL-G6

G1 1/4″/φ45.8(11牙/吋)

160

247

188.2

191793.1
RU06-WL-G10
RU06-WL-G16


Product size
